Model /Type |
10 Ton |
20 Ton |
30 Ton |
50 Ton |
80 Ton |
100 Ton |
150 Ton |
|
Bed To Ram |
243 |
276 |
330 |
358 |
400 |
450 |
510 |
|
Bed Size
L-R x F-B |
482x318 |
542x360 |
644x413 |
760x515 |
855x592 |
967x623 |
1100x665 |
|
Bed Opening |
100 |
120 |
125 |
160 |
170 |
210 |
215 |
|
Stoke
Length |
51 |
63 |
76 |
90 |
102 |
114 |
130 |
|
Crank Shaft
Die |
89 |
102 |
102 |
117 |
135 |
152 |
170 |
|
Gear Dia |
533 |
610 |
678 |
750 |
810 |
873 |
1041 |
|
Fly Wheel
Dia |
457 |
600 |
660 |
700 |
762 |
864 |
1100 |
|
Hole in Ram
for Die Clamping |
32 |
32 |
37 |
46 |
5 |
53 |
57 |
|
Floor To
Top Bed |
735 |
726 |
773 |
836 |
820 |
850 |
772 |
|
Over all
Height With Motor (App) |
1680 |
1825 |
2010 |
2200 |
2350 |
2615 |
2750 |
|
Floor Area
Required (App.) L-R x F-B |
850x620 |
850x727 |
1013x715 |
1700x885 |
1265x1000 |
1345x1145 |
1500x1168 |
|
No. Of
Stockes Per Minute |
55 |
50 |
45 |
40 |
40 |
40 |
28 |
|
Moter R.P.M |
1440 |
1440 |
1440 |
1440 |
1440 |
1440 |
1440 |
|
Motor Power
Required in B.H.P |
2 |
2 |
3 |
5 |
7.5 |
10 |
15 |
|
weight
approx in Kgs. |
700 |
1400 |
1800 |
2800 |
3800 |
5500 |
7000 |
